Steel Roof Bracing at Surat Railway Station
A view of steel roof framing and diagonal bracing at Surat railway station, Gujarat, with several members meeting at a connection.
Horizontal Vessel
A horizontal cylindrical vessel with rounded ends, showing the arrangement of steel supports beneath its shell.
Warehouse Cladding and Entrance Canopies
Warehouse exterior showing metal wall cladding, a pitched roof and entrance canopies. Internal framing and bracing are concealed in this view.
Underground Tank Installation
Horizontal cylindrical tanks are arranged side by side within an open excavation, with rounded ends and top fittings visible before backfilling.
Microbulk Cryogenic Tank
A vertical cylindrical tank carries exposed pipework, valves and fittings around its outer shell, with a base frame visible at ground level.
